Zebra Z4Mplus User Manual

Printer Setup
Calibration
Z4Mplus and Z6Mplus User Guide 15
Calibration
Auto Calibration
The Z4Mplus and Z6Mplus automatically calibrate on power up. During auto
calibration, the printer determines the label length and sensor settings.
Auto calibration occurs when the printer is turned on and each time the printer
recovers from an error condition. To clear an error, open and close the printhead
assembly and then press PAUSE. The printer begins auto calibration when all errors
have been cleared.
The results of the auto calibration are stored in the printer's memory and are retained
even if printer power is removed. These parameters remain in effect until the next
calibration is performed.
,
Note • If the front panel setting for MEDIA POWER UP or HEAD CLOSE are set
to LENGTH, NO MOTION, or FEED, the printer starts printing without auto
calibrating.

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
