Page #42 background imageLoading...
Page #42 background image
12 Z4Mplus and Z6Mplus User Guide
Printer Setup
Before You Begin
Print Mode
Print modes are displayed on the LCD on the front panel of the printer. Print modes
should match the media and printer options chosen. Print mode choices are listed in
the table below.
Mode Printer Option Action
Tear-Off Mode
(Default setting)
Use for most
applications.
Each label or strip of
labels can be torn off
after printing.
Peel-Off Mode Use only if printer has
the peel option.
Liner material is peeled
away from the label as it
is printed. After the
printed label is removed
the next label prints.
Cutter Mode Use only if printer has a
cutter option.
Printer automatically
cuts the label after it is
printed.
Rewind Mode Use only if printer has
the rewind option.
The media and/or liner
are rewound onto a core
as they are printed.

Table of Contents

Other manuals for Zebra Z4Mplus

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra Z4Mplus and is the answer not in the manual?

Zebra Z4Mplus Specifications

General IconGeneral
Print MethodThermal transfer or direct thermal
Resolution203 dpi
Max Print Width4.09 inches
Max Print Length39 inches
Max Print Speed10 inches per second
Memory4 MB Flash, 8 MB DRAM
InterfaceParallel, Serial
Media SensorsReflective and transmissive
Media Width0.79 inches to 4.5 inches
Media Length0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width2 inches to 4.33 inches
Power Requirements100-240 VAC, 50/60 Hz
Operating Temperature40°F to 105°F
Storage Temperature-40 to 140°F (-40 to 60°C)
Humidity20 to 85% non-condensing
