58 Z4Mplus and Z6Mplus User Guide
Configuration
Configuration
Configuration
After you have installed the media and ribbon, and the Power-On Self Test (POST) is
complete, the front panel displays PRINTER READY. If the printer fails its POST, see
Troubleshooting on page 97. Use the front panel display and the four keys directly
below it to set printer parameters for your application.
Enter Setup Mode
See the instructions below to enter the setup mode:
1. Press SETUP/EXIT:
2. Press PLUS (+) or MINUS (–) to scroll to the setting you wish to change.
3. Press SELECT to toggle the functionality of PLUS (+) and MINUS (–) keys.
4. Press PLUS (+) or MINUS (–) to increase or decrease the value, answer yes or no,
print a label, or select the digit you wish to change.
5. Press SELECT again to use PLUS (+) and MINUS (–) to scroll to the desired
menu item.
Note • Printers operating on an IP network can be quickly configured using
ZebraLink WebView (optional ZebraNet PrintServer II required). For information,
see PrintServer II User and Reference Guide (Zebra part number 45537L).
Note • An asterisk (*) in the upper left-hand corner of the display indicates that the
value displayed is different than the currently stored value.

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
