Zebra Z4Mplus User Manual

Z4Mplus and Z6Mplus User Guide 97
CHAPTER 7
Troubleshooting
This chapter discusses typical problems and their probable solutions.
Content
LCD Error Conditions and Warnings . . . . . . . . 98
Error Conditions . . . . . . . . . . . . . . . . . . . . . 98
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Print Quality Problems. . . . . . . . . . . . . . . . . . 103
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . 105
Communication Problems . . . . . . . . . . . . . 106
Printer Diagnostics . . . . . . . . . . . . . . . . . . . . 108
Power-On Self Test . . . . . . . . . . . . . . . . . . 108
Additional Printer Self Tests. . . . . . . . . . . . 108
Cancel Self Test . . . . . . . . . . . . . . . . . . . . 109
Pause Self Test . . . . . . . . . . . . . . . . . . . . . 110
Feed Self Test . . . . . . . . . . . . . . . . . . . . . . 111
Communications Diagnostics Test . . . . . . . . 112

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
