28 Z4Mplus and Z6Mplus User Guide
Printer Setup
Position the Label Sensor
Transmissive Sensor
The standard transmissive sensor is in a fixed position and enabled from the front
panel. For more detailed information, see SENSOR SELECT on page 64.
Configure the Software or Printer Driver
Many printer settings may also be controlled by your printer’s driver or label
preparation software. See the driver or software documentation for more information.
Standard Transmissive Sensor
Adjustable Transmissive Sensor
(Optional)

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
