Zebra Z4Mplus User Manual

64 Z4Mplus and Z6Mplus User Guide
Configuration
Configuration and Calibration Sequence
SENSOR SELECT Press SELECT to make change.
Setting the Sensor Select: Press PLUS (+) or MINUS (–)
to display other choices.
Default: Auto select
Selections: Auto select, reflective, transmissive
Press SELECT to accept the change.
This parameter tells the printer the sensor you wish to use.
Auto Select is compatible with most types of media.
However, if you encounter difficulties with calibration, see
Types of Media on page 10 to help you choose the
appropriate sensor for your media. Select the reflective
sensor with either continuous or non-continuous black mark
media; choose the transmissive sensor if you are using
noncontinuous web media.
PRINT METHOD Press SELECT to make change.
Selecting Print Method: Press PLUS (+) for the next
value; press MINUS (–) for the previous value.
Default: Thermal transfer
Selections: Thermal transfer, direct thermal
Press SELECT to accept the change.
The print method parameter tells the printer the method of
printing you wish to use: direct thermal (no ribbon) or
thermal transfer (using thermal transfer media and ribbon).
Selecting direct thermal when using thermal transfer media
and ribbon creates a warning condition, but printing
continues.
Display Shows Action/Explanation

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
