Zebra Z4Mplus User Manual

Z4Mplus and Z6Mplus User Guide 33
CHAPTER 4
Printer Basics
This chapter provides instructions for loading media and ribbon.
Contents
Printer Overview . . . . . . . . . . . . . . . . . . . . . . . 34
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . 34
Load Roll Media . . . . . . . . . . . . . . . . . . . . . . . 38
Tea r- Off Mo de . . . . . . . . . . . . . . . . . . . . . . . 38
Cutter Mode. . . . . . . . . . . . . . . . . . . . . . . . . 40
Peel-Off Mode . . . . . . . . . . . . . . . . . . . . . . . 42
Liner Take-Up Mode . . . . . . . . . . . . . . . . . . 44
Rewind . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Load Fanfold Media. . . . . . . . . . . . . . . . . . . . . 54
Load the Ribbon . . . . . . . . . . . . . . . . . . . . . . . 56
Remove the Ribbon. . . . . . . . . . . . . . . . . . . 58

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
