82 Z4Mplus and Z6Mplus User Guide
Configuration
Configuration and Calibration Sequence
IP ADDRESS* Press SELECT to make change.
IP Address: Press MINUS (–) to move to the next digit
position, press PLUS (+) to increase the value of the digit.
This parameter allows you to select the IP address if
permanent was chosen in IP RESOLUTION. (If dynamic
was chosen, the user cannot select the address.) For more
information, see ZebraNet Networking: PrintServer II
Installation and Users Guide.
SUBNET MASK* Press SELECT to make change.
Subnet Mask: Press PLUS (+) or MINUS (–) to display
other choices.
Default: Permanent (user must set)
Selections: Dynamic (user may set, but server can assign),
permanent
Press SELECT to accept the change.
This parameter selects the part of the IP address that is
considered to be part of the local network. It can be reached
without going through the default gateway.
DEFAULT GATEWAY* Press SELECT to make change.
Default Gateway: Press MINUS (–) to move to the next
digit position, press PLUS (+) to increase the value of the
digit.
Press SELECT to accept the change.
This parameter allows you to select the IP address that the
network traffic is routed through if the destination address is
not part of the local network.
* External ZebraNet PrintServer II or Cobra Internal option required
Display Shows Action/Explanation

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
