94 Z4Mplus and Z6Mplus User Guide

Routine Care and Adjustments

Cleaning Procedures

Lubrication

No lubrication is needed for this printer.

Number Description

Thumbscrew and Lock Washer

Cutter Shield

Upper Cutter Blade

Lower Cutter Blade
