Zebra Z4Mplus User Manual

Parallel Data Port
Parallel Data Port
Z4Mplus and Z6Mplus User Guide 133
36-Pin Connectors Description
1 nStrobe/HostClk
2 to 9 Data Bits 1 to 8
10 nACK/PtrClk
11 Busy/PtrBusy
12 PError/ACKDataReq
13 Select/Xflag
14 nAutoFd/HostBusy
15 Not used
16 and 17 Ground
18 +5V @ 750 mA
The maximum current draw may be limited by
option configuration.
19 to 30 Ground
31 nInit
32 nFault/NDataAvail
33 and 34 Not used
35 +5V through a 1.8KΩ Resistor
36 NSelectin/1284 active

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
