Zebra Z4Mplus User Manual

Memory Cards
Memory Cards
Z4Mplus and Z6Mplus User Guide 137
Note • Initialization of the PCMCIA card may take a few minutes; the Pause LED
flashes while the card initializes. If the card is already initialized, the Pause LED
flashes only once or twice. To verify that the card has successfully initialized, print a
configuration label and review it to see if the new memory card information is
listed.
Card Eject
Button
Notch
PCMCIA
Card
F
u
s
e
F
u
s
e

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
