Printer Basics

Load Roll Media

Z4Mplus and Z6Mplus User Guide 41

Number Description

Printhead Assembly

Transmissive Sensor

Label Supply Guide

Label Supply Hanger

Dancer

Label Guide

Printhead Open Lever

Cutter Module

Catch Tray
