Printer Basics

Load Roll Media

Z4Mplus and Z6Mplus User Guide 43

Number Description

Printhead Assembly

Transmissive Sensor

Media Supply Guide

Media Supply Hanger

Dancer

Media Guide

Printhead Open Lever

Peel Assembly

Label

Peel Lever

Tear-Off/Peel/Off Bar

101
