50 Z4Mplus and Z6Mplus User Guide
Printer Basics
Load Roll Media
13.Slide an empty core onto the take-up spindle; wrap the media around the core and
turn the take-up spindle counterclockwise to wind up the excess material.
14.Slide the rewind media guide against the media, and tighten the thumbscrew.
15.Close the printhead assembly.
16.The printer is paused (the Pause light is on), press
PAUSE to enable printing.
Note • The liner must be attached to the take-up spindle for the printer to operate
properly. Ensure the edge of the liner is flush against the backplate of the take-up
spindle.
