Printer Basics

Load Fanfold Media

Z4Mplus and Z6Mplus User Guide 53

Number Description

Printhead Assembly

Transmissive Sensor

Label Supply Guide

Label Supply Hanger

Dancer

Label Guide

Printhead Open Lever

Bottom Feed

Rear Feed
