Printer Basics

Load the Ribbon

Z4Mplus and Z6Mplus User Guide 55

Number Description

Strip Plate

Printhead Assembly

Release Knob

Tension Blades

Ribbon Take-Up Spindle

Ribbon Supply Spindle

Ribbon Sensor

Printhead Open Lever
