Zebra ZXP 1 Series User Manual

5: Replacement Procedures
Procedures
P1061942-001 Zebra ZXP Series 1 Card Printer Service Manual 125
5.6.12 Rear Cover
Step 1. With a TORX T10 driver, remove the two screws (SCR, PLAST, 4-.37L, 9.0 in-lb)
from the bottom of the Rear Cover.
Step 2. With a TORX T10 driver, loosen the two screws (SCR, PLAST, 4-.37L, 9.0 in-lb)
from the top of the Rear Cover.
Step 3. Remove the Rear Cover.
NOTE • This procedure uses Spare Kit # P1031925-143: KIT, SIDE PANELS BEZELS.

Zebra ZXP 1 Series Specifications

General

Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50-60 Hz
Print Technology	Dye sublimation
Card Capacity	100 cards (input hopper)
Card Size	CR-80 ISO 7810
Dimensions	368 mm (D)
Memory	32 MB
Operating Temperature	15°C to 30°C
Operating Humidity	20% to 65% non-condensing
Card Thickness	0.3mm - 1.06mm
