236 Zebra ZXP Series 1 Card Printer Service Manual P1061942-001
G: Upgrade Kit Instructions
Parts List
Special Tools
• TORX T10 Driver
• Flat-blade Screwdriver
Procedure
Preliminary Steps
Do the following:
a. Remove the Left Side Cover - - - - - - - - - - - - - - - - - - 237
b. Remove the Right Side Cover - - - - - - - - - - - - - - - - - 238
c. Remove the Bottom Cover - - - - - - - - - - - - - - - - - - - 239
d. Remove the Front Bezel - - - - - - - - - - - - - - - - - - - - 240
Upgrade Kit: P1031925-100; KIT, UPGRADE, MANUAL FRONT FEED
QTY PART NUMBER DESCRIPTION
1 210320-005 PANEL, FRONT, ZXP1
2 210321-005 MOUNT, SENSOR, ATM, ZXP1
1 806597G-204 SCR, PH, TORX, PLAST, 2-.25, ZN
1 P1060010 C/A, ATM INTERRUPTOR, ZXP1
1 P1061567 ASSY, CLEANNG CARTRIDGE
4 806822-001 FOOT,CYLINDRICAL,ADH-BACKED
Electric Shock Caution • Before performing any of the procedures in this section, set the
printer power to OFF (O) and disconnect the power cord.
Electrostatic Discharge Caution • This replacement procedure must be performed at a
static-free work station, an anti-static wrist strap must be worn and properly terminated, or
other appropriate protection must be used.
Caution • Before beginning any of the steps that follow, read completely through this
procedure. If you do not have the specified tools, or if any step(s) seem beyond your skill
or experience level, do not attempt the procedure. You may cause additional damage to
the printer.
