238 Zebra ZXP Series 1 Card Printer Service Manual P1061942-001
G: Upgrade Kit Instructions
Remove the Right Side Cover
Step 1. Locate the two screws (circled below) that hold the Right Side Cover in place.
Step 2. With a TORX T10 driver, loosen the two screws. When reinstalling the cover,
tighten the screws to 9.0 in-lbs.
Step 3. Remove the Right Side Cover.
Step 4. Close the Lid.
