Zebra ZXP 1 Series User Manual

5: Replacement Procedures
Procedures
P1061942-001 Zebra ZXP Series 1 Card Printer Service Manual 169
5.6.33 Pressure Rollers - Front and Back
Step 1. Locate the two Pressure Roller assemblies.
Step 2. With needle-nose pliers, remove the retaining springs (circled below) from both
sides of the Print Engine.
Step 3. Turn the Print Engine over (for access from bottom).
NOTE • This procedure uses Spare Kit # P1031925-074: KIT, PRESSURE ROLLERS.

Zebra ZXP 1 Series Specifications

General

Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50-60 Hz
Print Technology	Dye sublimation
Card Capacity	100 cards (input hopper)
Card Size	CR-80 ISO 7810
Dimensions	368 mm (D)
Memory	32 MB
Operating Temperature	15°C to 30°C
Operating Humidity	20% to 65% non-condensing
Card Thickness	0.3mm - 1.06mm
