General Description
1.1 Description
This manual contains installation, operation, and maintenance information for the Zebra ZXP
Series 1 Card Printer, manufactured by Zebra Technologies Corporation.
The printer provides full color dye sublimation or monochrome thermal transfer printing on
standard CR-80, ISO 7810 format, 2.12 inch by 3.38 inch (54 mm by 86 mm) PVC or
PVC Composite plastic 10-mil to 40-mil cards.
Zebra ZXP Series 1 Load-N-Go™ ribbon cartridges are used with an integrated card cleaning
roller for easy ribbon changing or replacement.
Several options are available, making the printers configurable for varied application
environments:
• Magnetic Encoder
• USB only or USB and 10/100 Ethernet
•CardSense
™
Single Card Feed Roller Kit
Its auto-switching external power supply uses inter-changeable power cords for
maximum flexibility.

Zebra ZXP 1 Series Specifications

General

Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50-60 Hz
Print Technology	Dye sublimation
Card Capacity	100 cards (input hopper)
Card Size	CR-80 ISO 7810
Dimensions	368 mm (D)
Memory	32 MB
Operating Temperature	15°C to 30°C
Operating Humidity	20% to 65% non-condensing
Card Thickness	0.3mm - 1.06mm
