264 ZXP Series 7 Card Printer Service Manual P1036102-007

Replacement Procedures for the Laminator

Procedures: Cassette Latch Assembly (Top & Bottom)

Step 6. Rotate the Laminator Levers in the direction indicated, lifting the levers up

and over the stops. Continue until rotation stops; then remove the levers.

Step 7. Set the Laminator Levers, Latch Plate, Cassette Latches, and Cassette

Torsion Springs aside.
