IM00120
MSC-3 Instruction Manual
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
• Press ESC to abandon the value change.
In some instances it is desirable to delay the de- activation of the digital output to assist with signal
interlock for example. This parameter sets the off delay for the digital output.
G09 TH(40,42) & G13 TH(60,62)
A thermistor input is available when the MSC-3 is tted with an extended features card.
G090 TH(40,42)
> DISABLED
Available Choices: ENABLED
DISABLED
• Press  once to begin.
• Use the ▲ / ▼ buttons to enable or disable thermistor input.
• Press  to conrm the choice.
The G09 TH(40,42) parameter enables thermal protection provided by an external thermistor, thermal
switch or thermal overload. An OT_THERM trip is generated when the resistance between the TH+ and
TH- terminals is greater than approximately 3300 ohms.
G10 AI(32,34) & G14 AI(52,54)
An extra analogue input is available when the MSC-3 is tted with an extended features option. This
extra analogue input can be congured to receive either: 0 to 5V, 0 to 10V or 0 to 20mA. Additionally the
input has a customisable span as well as a high and low compare thresholds.
G100 Input Type & G140 Input Type
G100 Input Type
> Volts
Available Choices: > Volts
> mAmps
• Press  once to begin input selection.
• Use the ▲ / ▼ buttons to select volts or milliamps input operation.
• Press  to conrm the choice. ESC to abandon the change.
The analogue input is congurable for voltage or milliamp input. This selection will congure the input
circuitry for either voltage input or current (mA) input without any need to access MSC-3 hardware. See
the Analogue Inputs and Spanning feature for details.
G101 MIN Input & G141 MIN Input
G101 MIN input
> 0.0 V
Range: 0.0...10.0 V or 0.0 to 20 mA
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
