MSC-3 Start Up
If the G020 AN IN mode is congured for > Volts then G021 MIN input will be displayed with units of
volts (V) otherwise G021 MIN input will be displayed with units of milliamps (mA). In either case the
minimum input for spanning is determined by this parameter. See the Analogue Inputs and Spanning
feature for details.
G022 MAX Input
G022 MAX Input
> 10.0V
Range: 0.0...10.0 V or 0.0 to 20 mA
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
• Press ESC to abandon the value change.
If the G020 AN IN mode is congured for > Volts then G022 MAX input will be displayed with units of
volts (V) otherwise G022 MAX input will be displayed with units of milliamps (mA). In either case the
maximum input for spanning is determined by this parameter. See the Analogue Inputs and Spanning
feature for details.
G023 Ref @MIN in
G023 Ref @MIN In
0.0%
Range: -100.0...100.0 % of C03 MAX Hz
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
• Press ESC to abandon the value change.
Regardless of how the analogue input is congured the minimum reference for input spanning is
determined by this parameter. The G023 Ref @MIN in parameter corresponds to the
G021 MIN input to dene the input spanning conguration. See the Analogue Inputs and Spanning
feature for details.
G024 Ref @MAX in
G024 Ref @MAX In
100.0%
Range: -100.0...100.0 % of C03 MAX Hz
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
