MSC-3 Instruction Manual
In this example the analogue output is congured as a voltage output and it is currently outputting 1.76V
An example output display of an Extended Features Card tted to the right hand side option connector
is:
DO (59,61) 0
AO (56,58) 0.00V
M02 Date – Time
M02 Date - Time
2013-11-28 14:41
This display reveals the date and time of MSC-3 time keeping. The format for the date and time is:
“20yy-mm-dd hh:mm”.
kWhr & Hours Run
This is a menu for pass code access to additional menus that manage the kWhrs and Hours Run
accumulating meters
kWhr & Hours Run
• Press the  button once to begin pass code entry. The following display will appear:
ENTER Code:
9999
• The code to access the menus is xed to “1470”. Press the  button once to begin.
• Use the ▲ & ▼ buttons to set each code digit and  to set to the next digit.
• After all digits have been entered correctly, the rst menu will appear.
kWhr
kWhr:
0
• Press the  button once to begin. The cursor and rst digit will blink.
• Use the ▲ & ▼ buttons to set each digit and  to set to the next digit.
• After all digits have been entered, the cursor will disappear.
Hours Run
Hours Run:
0
• Press the  button once to begin. The cursor and rst digit will blink.
• Use the ▲ & ▼ buttons to set each digit and  to set to the next digit.
• After all digits have been entered, the cursor will disappear.
