MSC-3 Start Up
MSC-3 transportation sizes and weights
The table below lists the approximate dimensions and weights for MSC-3 models in the standard
packing material.
Model Enclosure Type Shipping Dimensions
Weight
without
Choke
Weight
with Choke
Packaging
MSC-3*3
MSC-3*5
MSC-3*7
MSC-3*11
Chassis A
IP30 / NEMA 1
(No DC Choke)
280 x 300 x 184mm
11 x 11.8 x 7.3in
4Kg
Carton
MSC-3*3
MSC-3*5
MSC-3*7
MSC-3*11
Optional DC Bus
Choke for
Chassis A
IP30 / NEMA 1
175 x 335 x 145mm
6.9 x 13.2 x 5.7in
3.6Kg
Choke only
MSC-3*3
MSC-3*5
MSC-3*7
MSC-3*11
Chassis A
IP66 / NEMA 4
330 x 387 x 380mm
13 x 15.2 x 15in
7.1Kg 10Kg
MSC-3*15
MSC-3*23
MSC-3*30
Chassis B
All types
540 x 400 x 360mm
21.3 x 15.7 x 14.2in
20Kg 25.6Kg
MSC-3*40 27.5Kg
MSC-3*55
Chassis C
All types
520 x 750 x 440mm
20.5 x 29.5 x 17.3in
46Kg 72Kg
Pallet
MSC-3*82 48Kg 74Kg
MSC-3*109 50Kg 76Kg
MSC-3*140 62Kg 80Kg
MSC-3*170 78Kg
MSC-3R220
All Chassis D
All types without
oor stand
610 x 1260 x 675mm
24.0 x 49.6 x 26.6 in
250Kg
MSC-3R260 260Kg
MSC-3R315 270Kg
MSC-3R360 300Kg
MSC-3R390 310Kg
MSC-3R430 320Kg
MSC-3R490 330Kg
