Zener MSC-3 User Manual

IM00120
139
IM00120
MSC-3 Instruction Manual
Parameter User Default
G042 ON Delay 0
G043 OFF Delay 0
G050 UNDER SPEED 20.0
G051 OVER SPEED 80.0
G06 REMOTE OVRD DISABLED
G070 T1 Interval 1
G071 T1 Mode Delay ON
G072 T2 Interval 1
G073 T2 Mode Delay ON
G080 DO Function RUN
G081 DO Sense DIRECT
G082 ON Delay 0
G083 OFF Delay 0
G09 TH(37,38) DISABLED
G100 Input Type Volts
G101 MIN Input 0.0
G102 MAX Input 10.0
G103 Ref @MIN in 0.0
G104 Ref @MAX in 100.0
G105 Hi Compare Level 8
G106 Lo Compare Level 2
G110 Output Type Volts
G111 AO Source Hz
G112 Signal min 0.0
G113 Signal max 50.0
G114 MIN Output 0.0
G115 MAX Output 5.0
G120 DO Function RUN
G121 DO Sense DIRECT
G122 ON Delay 0
G123 OFF Delay 0
G13 TH(37,38) DISABLED
G140 Input Type Volts
G141 MIN Input 0.0
G142 MAX Input 10.0
G143 Ref @MIN in 0.0
G144 Ref @MAX in 100.0
G145 Hi Compare Level 8
G146 Lo Compare Level 2
G150 Output Type Volts
G151 AO Source Hz
G152 Signal min 0.0
G153 Signal max 50.0
G154 MIN Output 0.0
Parameter User Default
G155 MAX Output 5.0
G160 Protocol none
G161 bits/sec 19200
G162 Parity Even parity
G163 MAC/Dev ID 1
G164 Dev Inst. 1
G165 Max Masters 127
G166 RUN SIGNALS FROM TERMINAL
G167 Terminator DISABLED
G168 Comms Lost Time 10
G169 Serial No. G1000000
H01 PB (%) 300.0
H02 Ti (sec/r) 2.0
H03 Td (sec) 0.00
H04 +Opt clamp 100.0
H05 -Opt clamp 0.0
H06 SV choice CONSOLE
H07 PV choice AI(10,11)
H08 PID Units %
H09 PID Scale 100.0
*Drive Specic
