MSC-3 Instruction Manual
MSC-3 Output Current Specications
Model
Continuous Current for
General Purpose Rating (A)
Typically variable torque
applications
Continuous Current for
Extended Duty Rating (A)
Typically constant torque
applications
Over Load Current
(A)
7
MSC-3*3 3.6 3.1 4.7
MSC-3*5 5.0 4.2 6.3
MSC-3*7 7.2 6.1 9.0
MSC-3*11 10.8 9.1 13.4
MSC-3*15 14.9 12.7 19.0
MSC-3*23 22.5 19.1 28.6
MSC-3*30 30.1 25.6 38.4
MSC-3*40 40.3 34.1 51.1
MSC-3*55 55.0 46.6 69.9
MSC-3*82 82.0 68.9 104.3
MSC-3*109 109 92.0 138.6
MSC-3*140 140 116.9 178.0
MSC-3*170 170 132.6 199.0
MSC-3R220 220 170.0 242.0
MSC-3R260 260 200.0 286.0
MSC-3R315 315 250.0 346.5
MSC-3R360 360 285.0 396.0
MSC-3R390 390 310.0 429.0
MSC-3R430 430 340.0 473.0
MSC-3R490 490 395.0 539.0
* L, R or J for models up to MSC-3 *40. L or R for models MSC-3 *55 and up.
These currents apply to all ranges MSC-3 at an ambient temperature of 40ºC (104ºF) independent of the
input voltage. MSC-3 may be applied at higher ambient temperatures at reduced ratings. Please consult
the factory for ratings for ambients above 40ºC (104ºF).
