MSC-3 Instruction Manual
When G06 REMOTE OVRD is enabled, the push button on the console can toggle between LOCAL
and REMOTE mode of operation. Refer to the I11 REMOTE feature for details of LOCAL and REMOTE
operation.
G07 TIMER CONFIG
Timer parameters such as timer intervals and timer type are congured within this menu. Refer to the
G01 Inpt fxn CFG menu timer signal source assignments. The output of timers, are available as signal
sources as well.
G070 T1 Interval & G072 T2 Interval
G070 T1 Interval
0 secs
G072 T2 Interval
0 secs
Range: 0...600 seconds
• Press to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press to accept the new value OR
• Press ESC to abandon the value change.
These values set the timing interval for each of the timers. The timing interval begins according to the
mode of the timer. See G071 T1 mode & G073 T2 mode below for details.
G071 T1 mode & G073 T2 mode
G071 T1 Mode
> Delay ON
G073 T2 Mode
> Delay OFF
Available Choices: > Delay ON
> Delay OFF
• Press to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press to accept the new value OR
• Press ESC to abandon the value change.
If the timer mode is > Delay ON, timing begins when the rising edge of the timer’s signal source is
detected and continues while ever the signal source is held on. The output of the timer is held off during
the timing interval and is held on when timing is complete AND the timer signal source is maintained on.
If the timer mode is > Delay OFF, timing begins when the falling edge of the timer’s signal source is
detected and continues while ever the signal source is held off. The output of the timer is held on during
the timing interval and is held off when timing is complete AND the timer signal source is maintained off.
The timing interval is controlled by G070 T1 Interval & G072 T2 Interval timer. See G070 T1 Interval &
G072 T2 Interval above for details.
G08 DO(39,41) & G12 DO(59,61)
