MSC-3 Start Up
D03 REVERSE
D03 REVERSE
> DISABLED
Available Choices: ENABLED
DISABLE
• Press once to begin.
• Use the ▲ / ▼ buttons to enable or disable reverse operation.
• Press to conrm the choice.
The MSC-3 is shipped with its reverse direction disabled to prevent damage to mechanical devices or
hazardous equipment operation caused by the motor running backwards.
D04 DC INPUT
D04 INPUT
> DISABLED
Available Choices: ENABLED
DISABLED
• Press once to begin.
• Use the ▲ / ▼ buttons to enable or disable DC input operation.
• Press to conrm the choice.
This feature allows the MSC-3 to operate from a DC Input supply. The DC Supply voltage should be at
least 1.414 times higher than the motor voltage.
D05 1 Phase Inpt
D05 1 Phase Inpt
> DISABLED
Available Choices: ENABLED
DISABLED
• Press once to begin.
• Use the ▲ / ▼ buttons to enable or disable DC input operation.
• Press to conrm the choice.
This feature allows the MSC-3 to operate from a single phase electrical supply.
D06 SKIP SPEED
In some systems, operating a motor within a certain range of speeds can cause system instability, which
may lead to hazardous or damaging conditions. The skip speed feature provides the MSC-3 a means
to avoid operation at these speeds. The MSC-3 allows the motor to accelerate or decelerate through
the speed range as normal, but will not permit the motor to settle in the troublesome speed range. The
diagram below shows how the speed prole is affected by a skip speed.
To Next Page
