MSC-3 Start Up
• Press  to accept the new value OR
• Press ESC to abandon the value change.
If the G100 Input Type is congured for > Volts then G101 MIN input will be displayed with units of
volts (V) otherwise G101 MIN input will be displayed with units of milliamps (mA). In either case the
minimum input for spanning is determined by this parameter. See the Analogue Inputs and Spanning
feature for details.
G102 MAX Input & G142 MAX Input
G102 MAX input
> 10.0 V
Range: 0.0...10.0 V or 0.0 to 20 mA
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
• Press ESC to abandon the value change.
If the G100 Input Type is congured for > Volts then G102 MAX input will be displayed with units of
volts (V) otherwise G102 MAX input will be displayed with units of milliamps (mA). In either case the
maximum input for spanning is determined by this parameter. See the Analogue Inputs and Spanning
feature for details.
G103 Ref @MIN in & G143 Ref @ MIN in
G103 Ref @MIN in
0.0%
Range: -100.0...100.0 % of C03 MAX Hz
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
• Press ESC to abandon the value change.
Regardless of how the analogue input is congured the minimum reference for input spanning is
determined by this parameter. The G103 Ref @MIN in parameter corresponds to the
G101 MIN input to dene the input spanning conguration. See the Analogue Inputs and Spanning
feature for details.
G104 Ref @MAX in & G144 Ref @ MAX in
G04 Ref @MAX In
100.0%
Range: -100.0...100.0 % of C03 MAX Hz
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
