• Press  to conrm the choice. ESC to abandon the change.
Making or braking contact closure on this input activates (or deactivates) timer #2.
See G07 TIMER CONFIG for timer behaviour.
I16 Selector 1, I17 Selector 2 and I18 Selector 3
I16 Selector 1
> OFF
I17 Selector 2
> OFF
I18 Selector 3
> OFF
Available Choices for each function: See the list of the G01 Inpt fxn CFG menu
• Press  once to begin input selection.
• Use the ▲ / ▼ buttons to select a digital signal source.
• Press  to conrm the choice. ESC to abandon the change.
These inputs form a unique combination for the reference selector. See the Reference Selector feature
description for details
G02 AI(10,11) Cong.
The MSC-3 is equipped with a single analogue input as standard and can be congured to receive
either: 0 to 5V, 0 to 10V or 0 to 20mA. Additionally the input has a customisable span as well as a high
and low compare thresholds.
G020 Input Type
G020 Input Type
> Volts
Available Choices: > Volts
> mAmps
• Press  once to begin input selection.
• Use the ▲ / ▼ buttons to select volts or milliamps input operation.
• Press  to conrm the choice. ESC to abandon the change.
The analogue input is congurable for voltage or milliamp input. This selection will congure the input
circuitry for either voltage input or current (mA) input without any need to access MSC-3 hardware. See
the Analogue Inputs and Spanning feature for details.
G021 MIN Input
G021 MIN Input
> 0.0V
Range: 0.0...10.0 V or 0.0 to 20 mA
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
• Press ESC to abandon the value change.
