MSC-3 Instruction Manual
H07 PV choice
H07 PV choice
>AN IN
Available Choices: > AN IN
> LHS AN IN (if left-hand Extended Features card tted)
> RHS AN IN (if right-hand Extended Features card tted)
• Press once to begin a selection.
• Use the ▲ / ▼ buttons to select a reference.
• Press to conrm the choice.
The H07 PV choice is the analogue input on which the process variable is measured. Refer to the menus
of the selected analogue input for spanning, offset and limit alarm congurations.
H08 PID Units
H08 PID Units
> %
Available characters: 0…9,
A…Z, a…Z,
punctuation characters,
+, -, *, /, |, #, $, ^, &, !, ~,
{}, [], ()
• Press and the character to enter begins to ash
• Press ▲ & ▼ to move through the list of available characters
• Press to select the displayed character; the cursor moves to the next character OR the edit
completes
• Press the ESC button to abandon changes
The H08 PID Units are displayed on the PID run display and a total of 8 characters may be displayed as
units.
H09 PID Scale
H09 PID Scale
> 100.0
Available Range: 1.0…1000.0
• Press to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press to accept the new value OR
• Press ESC to abandon the value change.
The H09 PID Scale is used to scale the SV and PV values for the PID run display only and does not
affect the PID control loop.
