Zener MSC-3 User Manual

IM00120
71
IM00120
MSC-3 Instruction Manual
B01 MOTOR VOLTS
B01 MOTOR VOLTS
415 V
Range: 200...1000V (model dependant)
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
• Press ESC to abandon the value change.
The value entered is taken from the motor nameplate and is an important parameter of the motor control
algorithm
B02 MOTOR AMPS
B02 MOTOR AMPS
40.0 A
Range: 22.5%...171% of the MSC-3 current rating (model dependant)
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
• Press ESC to abandon the value change.
The value entered is taken from the motor nameplate and is an important parameter of the motor control
algorithm. In general the adjustment range is 22.5%...171% of MSC-3 rated current. However the actual
range of values is model dependant.
B03 MOTOR Hz
B03 MOTOR Hz
50.0 Hz
Range: 30...200 Hz
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
• Press ESC to abandon the value change.
The value entered is taken from the motor nameplate and is an important parameter of the motor control
algorithm.
