MSC-3 Start Up
Binary Values
Instance ID Object Name Description Active Text Inactive Text Present
Value
Access
BV0 Run fwd Run FWD Command Active Inactive C
BV1 Run rev Run REV Command Active Inactive C
BV2 Reset Reset Command RESETTING Inactive W
BV3 ESO ESO Mode ESO ACTIVE Inactive C
BV4 Remote Remote Status Remote Local R
BV5 Enabled Enable Status Enabled Disabled R
BV6 Switching Switching Status Switching Output Off R
BV7 Powered up Power Up Status Powered Up Warming Up R
BV8 Buscharged Bus Charged Status Bus Charged Charging R
BV9 Ramping to
stop
Ramping Status Ramping to Stop Clear R
BV10 Coasting Coasting Status Coasting Clear R
BV11 ARfailed Auto Restart Status AUTO RESTART
FAILED
Ready R
BV12 OPTSC Output Short Status OUTPUT SHORT Clear R
BV13 Overvoltage Over Voltage Trip OVERVOLTAGE Clear R
BV14 Overcurrent Over Current Trip OVERCURRENT Clear R
BV15 DC low DC Low Trip DC LOW Clear R
BV16 Power fail Power Fail Trip POWER FAIL Clear R
BV17 Over temp Over Temp Trip OVERTEMPERATURE Clear R
BV18 I2t trip I2t Trip I2t TRIP Clear R
BV19 Tripped Trip Status TRIPPED Clear R
BV20 Vlimit Voltage Limit Active Inactive R
BV21 Climit Current Limit Active Inactive R
BV22 Zero speed At Zero Speed Zero Speed Turning R
BV23 At speed At Speed Status At Commanded speed Speed
Changing
R
BV24 Run Run Status Running Stopped R
Present Value Access:
R = Read only
W = Writeable
C = Commandable
Commandable objects support priority arrays and relinquish defaults.
