MSC-3 Start Up
CAUTION!
MOTOR MAY START
WITHOUT NOTICE
CHECK WIRING
CAREFULLY...
The message is intended as a warning and an opportunity to conrm that terminal wiring is suited to the
factory default settings, otherwise unexpected drive operation may result.
• Pressing the button will cause the following message to appear:
CONTINUE WITH
CUSTOM LOAD?
• Press again to load factory defaults as the current set of parameters OR
• Press ESC to continue with the existing set of parameters
Save Custom Defaults?
It is recommended to save newly congured parameters after an MSC-3 is rst set up for an application.
Called “Custom Defaults”, new and existing parameters form a known conguration that serve as a
reference for future changes to the MSC-3 and its application. This menu provides a way to save the
current set of parameters as the “Custom Defaults”.
Save Custom
Defaults?
By loading custom defaults the MSC-3 may be restored to a known conguration after many parametric
changes have been made.
• Press to store the current set of parameters as commissioned defaults OR
• Press ESC to abandon parameter storage.
Upload/Download Connection
To facilitate MSC-3 conguration and software update an upload / download connection may be
established to a computer. The connection provides a convenient transfer of conguration and software
code les. To minimise hazardous operation the upload / download connection operates off-line. As a
result the MSC-3 must be in LOCAL mode and the motor stopped before prior to connecting.
B00 MOTOR Menu
This menu allows for the entry of motor nameplate information. Press ▲ / ▼ buttons to view and modify
motor volts, motor amps, motor Hz and motor rpm.
To Next Page
