MSC-3 Instruction Manual
Analog Values
Instance ID Object Name Description Units Present Value
Access
AV0 Cpreset Speed reference % C
AV1 Preset Preset analog value for general use % C
AV2 Accel time Acceleration time 0 - max speed seconds C
AV3 Decel time Deceleration time max speed - 0 seconds C
AV4 S time S characteristic of acceleration and
deceleration
seconds C
AV5 Current limit Current limit Amps C
AV6 AR allowed Number of auto restarts allowed - C
AV7 AR clear time Running time without trip to clear
auto start counter
minutes C
AV8 Under speed Set point for under speed alarm % C
AV9 Over speed Set point for over speed alarm % C
AV10 Speed Motor speed RPM R
AV11 Speed Motor speed % R
AV12 Frequency VFD output frequency Hz R
AV13 Load Load torque % R
AV14 Current Motor phase current Amp R
AV15 DC Volts DC bus voltage Volt R
AV16 Power Power to motor kW R
AV17 AC Volts AC Line Voltage Volt R
AV18 Temp Heatsink temperature Degree C R
AV19 I2T used Amount of the thermal capacity of
the motor used
% R
Accumulators
Instance ID Object Name Description Units Present Value
Access
ACC0 kWh kWh consumed by the motor kWh R
ACC1 Hours Run Number of motor operation
hours
hours R
Present Value Access:
R = Read only
W = Writeable
C = Commandable
Commandable objects support priority arrays and relinquish defaults.
