MSC-3 Start Up
Contact closure on this input means that the MSC-3 will follow the control inputs on the terminal strip
and the motor will run at the speed set by the Remote speed reference. When the contact is opened the
MSC-3 will be controlled from the console and will run at the speed set by the Local speed reference.
This input requires other terminals to stop and start the motor.
I12 EXTERN ALARM
I12 EXTERN ALARM
> OFF
Available Choices: See the list of the G01 Inpt fxn CFG menu
• Press once to begin input selection.
• Use the ▲ / ▼ buttons to select a digital signal source.
• Press to conrm the choice. ESC to abandon the change.
Contact closure on this input registers a trip and the status message “EX ALARM” is displayed.
I13 EXTERN WARN
I13 EXTERN WARN
> OFF
Available Choices: See the list of the G01 Inpt fxn CFG menu
• Press once to begin input selection.
• Use the ▲ / ▼ buttons to select a digital signal source.
• Press to conrm the choice. ESC to abandon the change.
Contact closure on this input displays the status message “EX WARN”.
I14 T1 Input
I14 T1 Input
> OFF
Available Choices: See the list of the G01 Inpt fxn CFG menu
• Press once to begin input selection.
• Use the ▲ / ▼ buttons to select a digital signal source.
• Press to conrm the choice. ESC to abandon the change.
Making or braking contact closure on this input activates (or deactivates) timer #1.
See G07 TIMER CONFIG for timer behaviour.
I15 T2 Input
I15 T2 Input
> OFF
Available Choices: See the list of the G01 Inpt fxn CFG menu
• Press once to begin input selection.
• Use the ▲ / ▼ buttons to select a digital signal source.
