MSC-3 Start Up
Your MSC-3 Setup Notes
Photocopy this page or complete in pencil Date
Site Designator MSC-3 Serial No.
Parameter User Default
A01 Menu Lock UNLOCKED
A02 Def. Display METER DISPLAY
A030 Run Display Format 999.9
A031 Run Display Scale 50.0
A032 Run Display Units Hz
B01 MOTOR VOLTS *
B02 MOTOR AMPS *
B03 MOTOR Hz *
B04 MOTOR RPM *
C10 MIN Hz 0
C011 IDLE DELAY 0
C012 RESUME Hz 0
C02 MAX Hz *
C030 ACCEL TIME 10.0
C031 DECEL TIME 10.0
C032 S TIME 0.01
C033 DUAL RAMP DISABLED
C034 ESO RAMP 10.0
C040 FLUX PLUS 0.0
C041 HiSpd Flux+ DISABLED
C05 SLIP COMP % 0.0
C06 AUDIBLE FREQ 2kHz
D01 CURRENT LIM *
D020 I2t *
D021 I2t zero Hz *
D022 I2t CNR Hz 10.0
D03 REVERSE DISABLED
D04 DC INPUT DISABLED
D05 1 Phase Inpt DISABLED
D060 SKIP SPEED 30
D061 SKIP RANGE 0
E01 COAST STOP DISABLED
E02 DYNAMIC BRK DISABLED
E030 ARs ALLOWED 0
E031 AR CLR TIME 1200
E04 Reset by PF DISABLED
E05 Motor Resync DISABLED
E06 LC CONTROL DISABLED
F01 REMOTE AI(10,11)
F02 LOCAL CONSOLE
F03 ESO F105 Preset 6
F04 JOGFWD F105 Preset 6
F05 JOGREV F105 Preset 6
F06 USER REF 1 AI(10,11)
Parameter User Default
F07 USER REF 2 CONSOLE
F080 PERSISTENT DISABLED
F081 STOP RESET DISABLED
F09 COMMS PRESET 60.0
F100 PRESET 1 10.0
F101 PRESET 2 20.0
F102 PRESET 3 30.0
F103 PRESET 4 40.0
F104 PRESET 5 50.0
F105 PRESET 6 60.0
F106 PRESET 7 70.0
F107 PRESET 8 80.0
I00 FWD & LATCH D3(4)
I01 REV & LATCH OFF
I02 ~STOP D2(3)
I03 FWD OFF
I04 REV OFF
I05 UP OFF
I06 DOWN OFF
I07 RESET D1(2)
I08 ESO OFF
I09 JOGFWD OFF
I10 JOG REV OFF
I11 REMOTE D4(5)
I12 EXTERN ALARM OFF
I13 EXTERN WARN OFF
I14 T1 Input OFF
I15 T2 Input OFF
I16 Selector 1 OFF
I17 Selector 2 OFF
I18 Selector 3 OFF
G020 Input Type Volts
G021 MIN Input 0.0
G022 MAX Input 10.0
G023 Ref @MIN in 0.0
G024 Ref @MAX in 100.0
G025 Hi Compare Level 8
G026 LoCMP Level 2
G030 RL Function RUN
G031 RL Sense DIRECT
G032 ON Delay 0
G033 OFF Delay 0
G040 RL Function TRIP
G041 RL Sense DIRECT
