Zener MSC-3 User Manual

IM00120
85
IM00120
MSC-3 Instruction Manual
F01 REMOTE
F01 REMOTE REF
> AN IN
Available Choices: > AI(10,11)
> CONSOLE
> PID OUTPUT
> AI(32,34) (Extended Features card tted on the left-hand side)
> AI(52,54) (Extended Features card tted on the right-hand side)
> COMMS REF
> F100 PRESET1
> F101 PRESET2
> F102 PRESET3
> F103 PRESET4
> F104 PRESET5
> F105 PRESET6
> F106 PRESET7
> F107 PRESET8
> REF SELECT
> ZERO REF
• Press  once to begin.
• Use the ▲ / ▼ buttons to select a reference.
• Press  to conrm the choice.
When the drive is operating in remote mode the MSC-3 will take its speed reference from the selected
reference source.
F02 LOCAL
F02 LOCAL REF
> CONSOLE
Available Choices: (See the list for F01 REMOTE)
• Press  once to begin.
• Use the ▲ / ▼ buttons to select a reference.
• Press  to conrm the choice.
When the drive is operating in local mode the MSC-3 will take its speed reference from the selected
reference source.
