MSC-3 Instruction Manual
• Press  once to begin input selection.
• Use the ▲ / ▼ buttons to select the output function for relay #1 operation.
• Press  to conrm the choice. ESC to abandon the change.
G031 RL1 Sense
G031 RL1 Sense
> DIRECT
Available Choices: > DIRECT
> INVERT
• Press  once to begin input selection.
• Use the ▲ / ▼ buttons to select direct or inverted relay operation.
• Press  to conrm the choice. ESC to abandon the change.
This menu allows relay #1 to be inverse acting for those applications that need inverted contact
behaviour.
G032 RL1 TON
G032 RL1 TON
0 secs
Range: 0...600 seconds
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
• Press ESC to abandon the value change.
In some instances it is desirable to delay the activation of a relay to assist with signal interlock for
example. This parameter sets the relay on delay for relay #1
G033 RL1 TOFF
G033 RL1 TOFF
0 secs
Range: 0...600 seconds
• Press  to edit the value.
• Press ▲/ ▼ to make changes to the value.
• Press  to accept the new value OR
