Section 4 Configuration Configuring EtherNet/IP Device
9ARD000014-600 A 137
The Hardware Editor contains three tabs — Settings, Connections and Unit Status.
The parameters for configuring the EtherNet/IP device are found in the Settings tab.
Configure the parameters according to the description of parameters given in
Table 23.
Tabl e 23. Settings for EtherNet/IP Device Unit
Parameter Data Type Unit Min Max
Editable
/Read
Only
Description
Vendor ID Dint - - - Read
Only
ABB vendor Identification number.
Product
Typ e
Dint - - - Read
Only
Device Type to identify the device
profile of Ethernet/IP as
Communication adapter
device(0x0C).
Product
Code
Dint - - - Read
Only
Identification number for the
EtherNet/IP device within the
communication adapter profile of
adapter.
Major
Revision
Dint - - - Read
Only
Major revision of the EtherNet/IP
device.
Minor
Revision
Dint - - - Read
Only
Minor revision of the EtherNet/IP
device.
Electronic
Key
VendorID
Enum 0 1 Editable Criteria that can be specified by user
for EtherNet/IP to accept connection
from CI873 only when Vendor ID of
EtherNet/IP configured in Control
Builder matches with the Vendor ID of
EtherNet/IP device in the network.
Values are:
Enable Keying, Disable Keying
Upon modification, connection
between EtherNet/IP and CI873 gets
disconnected and connected again.
