Section 4 Configuration Configuring Logix 5000 series PLC Unit
9ARD000014-600 A 143
The Hardware Editor contains three tabs — Settings, Connections and Unit Status.
The parameters for configuring the Control Logix PLC device are found in the
Settings tab. Configure the parameters according to the description of parameters
given in Table 24.
Tabl e 24. Settings for Allen Bradley Control Logix PLC
Parameter Data Type Unit Min Max
Editable
/Read
Only
Description
IP Address String - - - Editable The IP address of the PLC unit on the
network. It must be an IP address on
the same subnet as where the CI873
is placed.
If the IP address is blank, then first
three fields are taken from its parent
CI873 IP address and the fourth is
taken from its hardware tree position.
Upon modification, connection of
CI873 with the PLC unit is re-
established.
Slot Number Dint - - - Editable The slot position occupied by the
PLC in the chassis.
ReceiveDat
aFrom
O2TRPI
Dint ms 10 500 Editable Requested Packet Interval in
milliseconds for O->T packets.
Upon modification, connection with
the PLC unit is re-established.
ReceiveDat
aFrom
T2ORPI
Dint ms 10 500 Editable Requested Packet Interval in
milliseconds for T->O packets.
Upon modification, connection with
the PLC is re-established.
Class 3
Enabled
Enum - - - Editable This parameter is to enable/disable
the class 3 support.
