Section 4 Configuration Configuring S200 I/O Modules
9ARD000014-600 A 153
The Hardware Editor contains four tabs — Settings, Connections, Status and Unit
Status. The parameters for configuring the S200 I/O Modules are found in the
Settings tab. Configure the parameters according to the description of parameters
given in Table 26.
These parameters are common for all the S200 I/O Modules.
Apart from these there are specific settings to be done for 200-IP2 and 200-IP4 I/O
Modules.
Table 26. Parameters on S200 IO modules
Parameter
Default
Value
Type Unit Min Max Description Consequence
Connection
O2TRPI
500 dint ms 10 1000 Requested Packet
Interval for O->T
packets.
Connection
with the IO
module is
re-established
Connection
T2ORPI
500 dint ms 10 1000 Requested Packet
Interval for T>O
packets.
Connection
with the IO
module is
re-established
Connection
Timeout
Multiplier
4 dint - 0 7 Specifies the multiplier
applied to RPI to obtain
the connection time-out
value used for
establishing implicit
messaging connection.
Refer Ta bl e 1 for
connection time-out
multiplier
Connection
with the IO
module is
re-established
