ABB AC 800M

Appendix A Troubleshooting EDS File
9ARD000014-600 A 225
6 The eds file <eds
file name> is not
compatible with the
adapter being
imported. The
import will proceed
with the other
compatible IO
modules and adapter
The particular IO
module file is not
compatible with the
adapter which is
selected by the
user. So the import
will proceed by
avoiding that
particular file.
Modular
EtherNet/IP/
DeviceNet
The IO module that is
incompatible with the
adapter shall not be
considered, and the
import will continue.
7 Atleast one
selected IO eds
file Should be
compatible with the
adapter being
imported. The
import will not
proceed only with
adapter
None of the IO
modules are
compatible with the
adapter which is
selected.
Modular
EtherNet/IP/
DeviceNet
Select the IO module
that is compatible with
the adapter to
continue the import.
8 The EDS file name
used to invoke the
wizard has special
characters outside
the permissible
ASCII range.
Proceeding with the
import would lead
to an error in
saving the
generated HWD file.
Please modify the
EDS file name and
proceed with the
import process.
The EDS file name
has illegal
characters which
are not allowed by
DIW
EtherNet/IP/
DeviceNet
Import will abort. 
Rename the EDS file
so that it does not
have special
characters. After this,
start the import for the
EDS file.
Table 41. Messages - Import of EDS Files (Continued)
Sl
No
Message Reason
Applicability
Based on Device
Classification
Additional
Information and
Workaround
