c. Enter the port number in the Port Number field or select Use Default to
set the default value.
d. Under Wr
ite Tag 1, enter or select the following details:
– Se
rvice ID: Select CIP Table Write Service from the drop-down list.
This is the vendor specific CIP service to be executed to read or write the
data.
– Da
ta Type: Select data type from the drop-down list. After data type is
selected, Configured channels window is opened as shown in Figure 35.
The data type is defined for each tag for the Class 3 connections. The
follo
wing are the supported standard data types:
–SINT
–INT
–DINT
–REAL
– BOOL
–DWORD
–USINT
– UDINT
–BYTE
–WORD
– STRUCTURE. If this data type is selected, DataSiz
e dialog box appears
as shown in Figure 33.
If the 64-bit data type is Dword, the data can be split into 2 Dword each of 32-bit
data type.

64 bit data of any other data type lik
e Real and Integer is not supported.
– N
o. of elements: Type the number of data elements of the particular data
type, that is read or written from or to Allen Bradley PLC device.
