Parameters 121
06.20 Constant speed status
word
Constant speed/frequency status word. Indicates which
constant speed or frequency is active (if any). See also
parameter 06.19 Speed control status word, bit 7, and
section Constant speeds/frequencies.
This parameter is read-only.
-
0000h…FFFFh Constant speed/frequency status word. 1 = 1
06.21 Drive status word 3 Drive status word 3.
This parameter is read-only.
-
0000h…FFFFh Drive status word 1. 1 = 1
06.29 MSW bit 10 selection Selects a binary source whose status is transmitted as bit
10 (User bit 0) of parameter 06.11 Main status word.
Above limit
False 0. 0
True 1. 1
Above limit Bit 10 of 06.17 Drive status word 2.2
Other [bit] Source selection (see Terms and abbreviations). -
06.30 MSW bit 11 selection Selects a binary source whose status is transmitted as bit
11 (User bit 0) of 06.11 Main status word.
Ext ctrl loc
False 0. 0
True 1. 1
Ext ctrl loc Bit 11 of 06.01 Main control word.2
Other [bit] Source selection (see Terms and abbreviations). -
No. Name/Value Description Default
FbEq 16
Bit Name Description
0 Constant speed 1 1 = Constant speed or frequency 1 selected
1 Constant speed 2 1 = Constant speed or frequency 2 selected
2 Constant speed 3 1 = Constant speed or frequency 3 selected
3 Constant speed 4 1 = Constant speed or frequency 4 selected
4 Constant speed 5 1 = Constant speed or frequency 5 selected
5 Constant speed 6 1 = Constant speed or frequency 6 selected
6 Constant speed 7 1 = Constant speed or frequency 7 selected
7…15 Reserved
Bit Name Description
0 DC hold active 1 = DC hold is active
1 Post-magnetizing
active
1 = Post-magnetizing is active
2 Motor pre-heating
active
1 = Motor pre-heating is active
3 PM smooth start
active
1 = PM smooth start is active
4 Rotor position
known
1 = Rotor position is known
5 DC brake active 1 = DC brake is active
6…15 Reserved
