Parameters 191
28.22 Constant frequency
sel1
When bit 0 of parameter 28.21 Constant frequency
function is 0 (Separate), selects a source that activates
constant frequency 1.
Note: The default value depends on the selected macro.
See chapter Control macros on page 27.
When bit 0 of parameter 28.21 Constant frequency
function is 1 (Packed), this parameter and parameters
28.23 Constant frequency sel2 and 28.24 Constant
frequency sel3 select three sources whose states activate
constant frequencies as follows:
DI2
Always off 0 (always off). 0
Always on 1 (always on). 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
Supervision 1 Bit 0 of 32.01 Supervision status.24
Supervision 2 Bit 1 of 32.01 Supervision status.25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
Other [bit] Source selection (see Terms and abbreviations). -
28.23 Constant frequency
sel2
When bit 0 of parameter 28.21 Constant frequency
function is 0 (Separate), selects a source that activates
constant frequency 2.
When bit 0 of parameter 28.21 Constant frequency
function is 1 (Packed), this parameter and parameters
28.22 Constant frequency sel1 and 28.24 Constant
frequency sel3 select three sources that are used to
activate constant frequencies. See table at parameter
28.22 Constant frequency sel1.
For the selections, see parameter 28.22 Constant
frequency sel1.
Note: The default value depends on the selected macro.
See Control macros on page 27
.
Always off
No. Name/Value Description Default
FbEq 16
Source defined
by par. 28.22
Source defined
by par. 28.23
Source defined
by par. 28.24
Constant frequency
active
000 None
1 0 0 Constant frequency 1
0 1 0 Constant frequency 2
1 1 0 Constant frequency 3
0 0 1 Constant frequency 4
1 0 1 Constant frequency 5
0 1 1 Constant frequency 6
1 1 1 Constant frequency 7
