244 Parameters
40.45 Set 1 sleep boost time Defines a boost time for the sleep boost step. See
parameter 40.46 Set 1 sleep boost step.
0.0 s
0.0…3600.0 s Sleep boost time. 1 = 1 s
40.46 Set 1 sleep boost step When the drive is entering sleep mode, the process
setpoint is increased by this value for the time defined by
parameter 40.45 Set 1 sleep boost time.
If active, sleep boost is aborted when the drive wakes up.
0.0 PID
customer
units
0.0…200000.0 PID
customer units
Sleep boost step. 1 = 1 PID
customer
unit
40.47 Set 1 wake-up
deviation
Defines the wake-up level as deviation between process
setpoint and feedback.
When the deviation exceeds the value of this parameter,
and remains there for the duration of the wake-up delay
(40.48 Set 1 wake-up delay), the drive wakes up.
See also parameter 40.31 Set 1 deviation inversion.
0.00 PID
customer
units
-200000.00...200000.0
PID customer units
Wake-up level (as deviation between process setpoint
and feedback).
1 = 1 PID
customer
unit
40.48 Set 1 wake-up delay Defines a wake-up delay for the sleep function to prevent
nuisance wake-ups. See parameter 40.47 Set 1 wake-up
deviation.
The delay timer starts when the deviation exceeds the
wake-up level (40.47 Set 1 wake-up deviation), and resets
if the deviation falls below the wake-up level.
0.50 s
0.00…60.00 s Wake-up delay. 1 = 1 s
40.49 Set 1 tracking mode Activates (or selects a source that activates) tracking
mode. In tracking mode, the value selected by parameter
40.50 Set 1 tracking ref selection is substituted for the PID
controller output. See also section Tracking (page 73).
1 = Tracking mode enabled
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status
, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
Supervision 1 Bit 0 of 32.01 Supervision status.21
Supervision 2 Bit 1 of 32.01 Supervision status.22
Supervision 3 Bit 2 of 32.01 Supervision status.23
Supervision 4 Bit 3 of 32.01 Supervision status 24
Supervision 5 Bit 4 of 32.01 Supervision status 25
Supervision 6 Bit 5 of 32.01 Supervision status 26
Other [bit] Source selection (see Terms and abbreviations). -
40.50 Set 1 tracking ref
selection
Selects the value source for tracking mode. See
parameter 40.49 Set 1 tracking mode.
Not selected
Not selected None. 0
No. Name/Value Description Default
FbEq 16
