9902 APPLIC
MACRO
Selects the application macro. See chapter Application
macros on page 101.
ABB
STANDA
RD
ABB
STANDARD
Standard macro for constant speed applications 1
3-WIRE 3-wire macro for constant speed applications 2
ALTERNATE Alternate macro for start forward and start reverse
applications
3
MOTOR POT Motor potentiometer macro for digital signal speed control
applications
4
HAND/AUTO Hand/Auto macro to be used when two control devices are
connected to the drive:
• Device 1 communicates through the interface defined by
external control location EXT1.
• Device 2 communicates through the interface defined by
external control location EXT2.
EXT1 or EXT2 is active at a time. Switching between
EXT1/2 through digital input.
5
PID CONTROL PID control. For applications in which the drive controls a
process value, eg pressure control by the drive running the
pressure boost pump. Measured pressure and the pressure
reference are connected to the drive.
6
PFC
CONTROL
PFC (Pump and fan control) macro for pump alternation
applications
7
SPFC
CONTROL
SPFC (Soft pump and fan control) macro for pump
alternation applications where lower pressure peaks are
desirable when a new auxiliary motor is started.
15
AC500
MODBUS
AC500 PLC macro. See section AC500 Modbus macro on
page 113 .
21
LOAD FD SET FlashDrop parameter values as defined by the FlashDrop
file. Parameter view is selected by parameter 1611
PARAMETER VIEW.
FlashDrop is an optional device for fast copying of
parameters to unpowered drives. FlashDrop allows easy
customization of the parameter list, eg selected parameters
can be hidden. For more information, see MFDT-01
FlashDrop user’s manual (3AFE68591074 [English]).
31
USER S1
LOAD
User 1 macro loaded into use. Before loading, check that
the saved parameter settings and the motor model are
suitable for the application.
0
All parameters
No. Name/Value Description Def/FbEq
